| Product Weight | 825g (with propellers) |
| Voltage Platform | 12-14S (LiPo) |
| Mounting Tube Diameter | Φ30mm |
| Signal Support | CAN/PWM (Compatible with 5V/3.3V) |
| Throttle Pulse Width | 1050-1950us (Fixed throttle) |
| Operating Temperature | -20~50℃ |
| Protection Rating | IPX6 |
| Maximum Thrust (Single-axis) | Maximum thrust 12.5kg (at sea level) |
| Recommended Thrust (Single-axis) | Recommended takeoff weight 3-6kg (at sea level) |
| Overcurrent Capability | 120A peak, maximum continuous current 70A |
| Maximum Operating Voltage | 63V |
| Communication Protocol | CAN |
| Motor Stator Size | 62*18mm |
| KV | 155KV |
| Diameter * Pitch | 24*9.0 |
| Material | Carbon fiber nylon composite |
| Weight | 109.6g |
| Foldable/Direct Propeller | Foldable propeller |
